M.2 PCIe NVMe EX Plus

M.2 PCIe NVMe EX plus is a PCIe NVMe M.2 2280 type Solid State Drive. It supports a max read speed of up to 3.4 GB/sec and a max write speed as fast as 3.0 GB/sec for Audio/Video Cache application. It also has a great performance of Random 4KB Read/Write up to 570K/660K IOPS.

Features

PCIe/NVMe Interface
Max Speed: Read up to 3.4GB/s, Write up to 3.0GB/S
Capacities up to 8TB

*Based on CrystalDiskMark v.7.0 and Asus P6T Motherboard. Perfomance may vary. Usable capacity is less than specified after formatting. Windows is a registered trademark of Microsoft.
Interface	PCIe/NVMe Gen3x4
Form Factor:	M.2 (2280)
Capacities:	500GB-8TB
NAND Flash:	TLC/QLC
Performance: (Access Time)	0.1ms
TLC: (Read/Write (MB/sec))	3400/3000
DRAM Cache:	256MB - 1GB
Power Supply:	3.3V +/-5%
Dimension: (mm)	22.0 x 80.0 x 3.8mm
Part Number:	FPI***20R7
Data Sheet:	M.2 PCIe NVMe EX Plus
